Double Action Tri Clamp 8 Bar Hygienic Ball Valve

Brand Name : OEM

Certification : ISO9001, 3A

Place of Origin : China

MOQ : 1pc

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 10,000pcs per month

Delivery Time : 7~30 days EXW.

Packaging Details : cartons and plywooden box

Model Number : OEM

Materials : AISI316L

Type : Hygienic Valves

Connection Type : Tri Clamp,Male Threaded

Diameter : 1/2'' - 4''

Specifications : 3A ASME BPE

MOQ : 1PC

Contact Now

Hygienic Sanitary Stainless Steel Three Way Tri Clamp Ball Valve with Pneumatic Actuator

Features and Specifications:

Pneumatic actuator	Type 1: Double action (NO or NC) ; Type 2: Spring automatic return
Air supply pressure	3-8 bar
Solenoid valve accessories	Input 110-240VAC, output 12-24VDC
Nominal diameter	Φ25-Φ100; 1"-4"
Working pressure	0-16 bar
Withstand temperature	-30~180°C (RPTFE)
Connection end	Male Threaded,Tri-Clamp
Body structure	3 way ball core L and T-type
Clamp end dimension	According to DIN, ISO, SMS, BS standards

Pneumatic actuator

Double acting: Air to open, air to close, air supply failure to keep the current position
Single acting air to open type: Air to open, interrupt air to close, air failure to close
Single acting air to close: Air to close, interrupt air to open, air failure to open
Optional choice: Reversing solenoid valve, limit switch box, air filter reducing valve, positioner, handle manual, lock up valve

Our Competitive Advantages:

We only purchase selected 304/316L stainless steel from reputated mill to guarantee the chemical composition and mechanical propertis.
We use forged valve body and disc to eliminate leakage defects.
Superior facilities and good experiences for fabrication.
In ability to improve and develop new design.
We prepare stock for most standard models for fast delivery
Low cost from bulk production will reduce your budget and improve your business.

Applications:

Our sanitary hygienic pneumatic thread three way ball valves meets the hygienic requirement in food, pharmaceutical and biotechnology production pipelines. They are widely used to change fluid flow directions and divide medium flows.

We also supply sanitary butterfly valve, sanitary flow diversion valve, sanitary CPM valve, sanitary regulating control valve, sanitary diaphragm valve, sanitary ball valve, sanitary sampling valve, sanitary safety valve, sanitary pressure reducing valve,etc...

If you have any inquiry for our other sanitary products,pls send us via email:sales@sanitary-valves-fittings.com

We will try our best to give you best price and best quality.

Double Action Tri Clamp 8 Bar Hygienic Ball Valve
